Fanuc CRX-10iA Assembly Robot Arm 10Kg Payload 1249mm Reach Collaborative Robot Arm

Brand Name : Fanuc

Model Number : CRX-10iA

Place of Origin : China

MOQ : 1

Price : 30000~20000

Payment Terms : T/T

Supply Ability : 5PCS/30Day

Delivery Time : According to requirement

Packaging Details : wooden box

Max. load capacity : 10 kg

Max. reach : 1249 mm

Controlled axes : 6

Repeatability (mm) : ± 0.04

Mechanical weight (kg) : 40

Maximum linear speed (mm/s) : 1000

Robot footprint [mm : 8

Controller : R-30iB Plus

Protection standard : IP67

Ambient temperature [° C : 8

Contact Now

Fanuc CRX-10iA Collaborative Robot Arm 10Kg Payload 1249mm Reach With SMC Robotic Gripper For Assembly Material Handling

Feature of Fanuc CRX-10iA

The CRX-10iA is highly protected against dust or oil leakages common in industrial environments and fully complies with ISO 10218-1 safety standards. Because of its very low weight, the CRX can be easily installed in a broad range of applications such as automated guided vehicles (AGV).

FANUC CRX series also offers the ideal solution for the food industry. The CRX-10iA and CRX-10iA/L robots can be equipped with NSF-H1 food-grade grease, white epoxy paint and rust/chemical resistant plating. This makes them the perfect choice for food industry applications.
Specification
Warranty of core components
1 Year
Core Components
Engine, Motor
Max. load capacity
10 kg
Max. reach
1249 mm
Controlled axes
6
Repeatability (mm)
± 0.04
Mechanical weight (kg)
40
Maximum linear speed (mm/s)
1000
Robot footprint [mm]
190
Controller
R-30iB Plus
Protection standard
IP67
Ambient temperature [° C]
0-45
Fanuc CRX-10iA Assembly Robot Arm 10Kg Payload 1249mm Reach Collaborative Robot Arm
Fanuc CRX-10iA Assembly Robot Arm 10Kg Payload 1249mm Reach Collaborative Robot Arm
Fanuc CRX-10iA Assembly Robot Arm 10Kg Payload 1249mm Reach Collaborative Robot Arm
